High Capacity Beans Ultrafine Powder Grinding Machine
Home > Products > Stainless Steel Sprocket > High Capacity Beans Ultrafine Powder Grinding Machine

High Capacity Beans Ultrafine Powder Grinding Machine


  • High Capacity Beans Ultrafine Powder Grinding Machine
  • High Capacity Beans Ultrafine Powder Grinding Machine
  • High Capacity Beans Ultrafine Powder Grinding Machine
  • High Capacity Beans Ultrafine Powder Grinding Machine

High Capacity Beans Ultrafine Powder Grinding Machine

    Payment Type: L/C,T/T,Western Union
    Terms of Trade: FOB,CFR,CIF
    Min. Order: 1 Bag/Bags
    Delivery Time: 20 Days
    Packaging: Wooden box package
    Productivity: 1-10t/h
    Brand: CWJX
    Transportation: Ocean,Land,Air
    Place of Origin: China
    Supply Ability: 30 sets/month
    Certificate: CE BV SGS ISO
    Port: Qingdao,Shanghai,Shenzhen

Basic Info

Model No.: CW-

Product Description

Product Description

pulverizer grinding machine

The universal pulverizer uses the high-speed relative motion seen by the movable Sprocket and the fixed sprocket to make the pulverized material crushed by the combined action of tooth impact, friction and material impact. The machine has simple structure, firmness, stable operation and good pulverization effect. The pulverized material can be directly discharged from the grinding chamber of the main machine, and the particle size can be obtained by replacing the mesh screen with different apertures, and the machine is all stainless steel. The inner wall of the casing is machined to achieve a smooth surface, which changes the phenomenon of rough and powder accumulation on the inner wall of the previous model, making the production of medicines, food, chemicals and other products more in line with national standards and meeting the requirements of GMP.

Universal crusher

Technical Specification

Model
20B
30B
40B
60B
80B
Production
20-150kg/h
30-300kg/h
40-800kg/h
80-1200kg/h
150-2000kg/h
Spindle speed
4500r/min
3800r/min
3400r/min
3000r/min
2100r/min
Feeding Size
6mm
10mm
12mm
15mm
20mm
Finished Size
12-120mesh
12-120mesh
12-120mesh
12-120mesh
12-120mesh
Motor
4
7.5
11
22
30
Dimension
700*900*1500
800*1100*1700
850*1200*1850
950*1300*1950
1100*1200*2100

Application

Pharmaceutical, food, chemical crushing material bulk material, hard material, hard crushing material hopper humidity requirements less than or equal to 5%


Universal crusher

Principle

1,Bidirectional pair wheels adopt the way of reverse rotation of front and back grinding wheels, thus this way improves the crushing effect. Double discs install the needle cylinders whose diameters are different, every part arrays needles and bars through the technology of three dimensional simulation, designing the layout rationally and thus it can control the materials to achieve the effective split effect in the gap of needle bar efficaciously.
2,Needles and bars can adopt the shape of hexagonal,square,wolf teeth and so on according to crushing materials. The shape of wolf teeth is all called corn cob rollermill, and this machine has the special effect for the engineering plastic with high melting point to flour at room temperature. Needle and bar mill adopt the way of quantitative feeding of screw, controlling the even motion of materials in the inward of millstone.
3,The ways of discharge are output in the natural state and discharge of negative pressure method. This machine does not have mesh screen in the chamber of grinding wheel, and it adjusts the fineness of crocus through the wire-speed of mill wheel, it can also classify materials through external grading method.

Detailed Images
Universal crusher
Pcking & Delivery

Universal crusher

Universal crusher

Our Company

Universal crusher

XINXIANG CHENWEI MACHINERY CO.,LTD

 Xinxiang Chenwei Machinery located in Xinxiang City,Henan Province,is specialized in providing solutions for material handling and processing,being in this field for over 30 years.
Main products cover screening and filtering equipment,conveying and lifting equipment,drying machine,crushing and grinding machine,mixer,packing machine,waste material recycling machine etc,Besides providing single equipment,we can also provide whole production line,such as dry mortar production line,wood pellet production line,pellet feed production line,organic fertilizer production.

We are qualified with ISO quality management system and CE certificate, all the main components are fine manufactured in our own factory with strict inspection, and quality is always our priority

Due to our continuous investment on R&D and upgrading in industrial application year by year, Chenwei Machinery had formed its own unique and beneficial characters in design and process technology. All the equipment are manufactured strictly under guideline of ISO 9001:2008 .

Till now, our products have been exported to USA, Canada, Korean,Poland, North Korea, Britain, Turkey, Sweden, Japan, Kazakhstan, Ukraine,Russia, Albania,Sri Lanka, Israel, Cyprus, Uzbekistan, Thailand,Egypt, India, Pakistan, Peru, Brazil etc.

We formed our own insight for biscuit and candy processing industry and our solutions are verified successfully for customers. Chenwei Machinery are always ready and expecting chances to serve you at home and abroad.
